The female threaded cross is designed for threaded connections from ø ½” to 4″ in hydraulic applications related to the distribution of pressurised fluids in irrigation and waterworks systems. The black high-impact UV-stabilised PP cross is equipped with four BSP (GAS) female threads and is designed and tested to guarantee a PN16 working pressure: equipped with metal reinforcement ring in diameters 3″ to 4″
In particular, it is used in drinking water transport systems in aqueducts and civil installations, in irrigation and gardening, geothermal systems, and for conveying wastewater and industrial water.
GENERAL CATALOGS AND TECHNICAL DATA SHEETS IN
VARIANT SIZE PN BAG BOX
14063-B ½” PN16 nd 600
14063-C ¾” PN16 nd 320
14063-D 1” PN16 nd 180
14063-E 1”¼ PN16 nd 100
14063-F 1"½ PN16 nd 80
14063-G 2" PN16 nd 20
14063-L 3" PN16 nd 24
14063-M 4" PN16 nd 12
*| UV-stabilised high-impact black propylene with high ageing stability |*
REINFORCING RING:
The presence of the reinforcement ring in couplings with female threads provides an additional guarantee in terms of resistance to operating pressures, especially at high temperatures and in the long term.
WORKING TEMPERATURES:
MIN= -10°C MAX= +80°C
REGULATION FOR DRINKING WATER:
DM 174-06/04/2004 (Italy), DM 23/04/2009 e Reg. UE n° 10/2011, W270 and KTW (Germany), ATA (Netherlands), Global Mark (Australia), ACS (France), WRAS (UK).
REFERENCE STANDARDS:
- Filetti BSP [BSP Threads]: UNI EN 10226 (ISO 7-1), BS 21, AS 1722.1
- Filetti NPT [NPT Threads]: ANSI-ASME B1.20.1
- Prove [Tests]: ISO 1167
